    High Performance PVC Fabric Freezer High Speed Door For Cold Storage

    Ask Lasest Price
    Brand Name : YUOU
    Model Number : YUOU-PVChigh speed door -6
    Certification : ISO9001
    Price : USD2000-3000/set
    Payment Terms : T/T, Western Union, MoneyGram, L/C,
    Supply Ability : 1000set /per month
    Delivery Time : 15-20days
    • Product Details
    • Company Profile

    High Performance PVC Fabric Freezer High Speed Door For Cold Storage

    High Performance PVC Fabric freezer high speed door for Cold Storage

    Description:
    Freezer High Speed Doors. A special type thermal insulated rapid rolling doors fit for freezers , cool rooms, and cold
    stores. It can reduce thermal transmission by fast opening and closing, and thermal insulated door curtain. For each
    door, it can help customer save energy cost by at least USD 8000 every year,than traditional normal speed cold room
    sliding doors.

    Features:
    1. High speed opening and closing
    The running speed can reach 2m/s, 10 times as traditional roller shutter door. This obviously improves passing effici-
    ency through it and enhances overall output.
    2. High frequency operation
    The operation frequency can reach more than 1000 times per day without any faults. This meets need of heavy tra-
    ffic in some areas.
    3. Good thermal-insulation
    Double skin is 0.8mm PVC fabric, and inside is filled with high-density insulating rock wool . Total Thickness of door
    panel : 20-40mm; With excellent thermal insulation performance. It can prevent thermal loss of the cold room and sa-
    ve energy
    4. It can work in extreme low temperature.
    There is heating device around the door to avoid freezing when door running.
    5. Excellent safety performance
    Dual protection design. Every door is equipped with safety photo sensor and proximity sensor, avoiding collision acci-
    dents and protecting passing human or vehicles.
    6. Complying with Food-grade and GMP norm
    Special design seal structure. PVC fabric is dust-proof and easy for cleaning.
    7. High safety protection
    Safety photo sensor. When there is human or vehicle under the door, the door will stop closing and get up automati-
    cally. This will avoid accident collisions.
    8. Self-repairing
    When there is a collision accident by forklift or other objects, the door will not be damaged. And it can recover autom-
    atically or semi-automatically under hand assistance. This design effectively reduces the maintenance and repair wo-
    rk caused by collisions.
    9. High air-tightness
    Special zipper design structure, connects the fabric and guide rails as a whole body, eliminating gap between them.It
    obviously improves overall seal performance and air tightness.

    Applications:
    Freezers, Cold Rooms, Cool Room, Food Warehouse, Drug Warehouse.

    MORE PARAMETERS
    Door Curtaina. PVC Curtain:Double layer with insulation material inside
    b. Thickness of PVC Curtain: 0.8mm+0.8mm

    Guide RailStainless steel /Aluminum alloy (Optional),T:2.0mm
    Zipper FunctionAutomatic repair function,good sealing and thermal insuation performance
    Special Functiona.Thermal Insulation: Insulation material inside PVC curtain
    b.Energy Saving: By short open/close time and make better sealing(zipper tight seal) to enhance temperature control
    c.Increase Productivity:Zipper on both side,self-repair fuction to avoid down-time and minimize maintenance cost
    d.Reduce Frost:Optional heating belt to avoid frost
    MotorServo motor
    Control SystemServo control system
    Working Frequency1000 Times/day
    Working Temperature25ºC below zero - 5ºC
    Surface TreatmentElectrostatic painting, various colors available
    Safetya.Photoelectric protection system or Optical grating(optional)
    b.Air chamber at the bottom(optional)
    SealingEPDM Rubber: Heat resistance, weather resistance and aging resistance
    Emergency OperationManual Swing Bar
